Compulite Color Scrollers Whisper D 10"（コンピュライトカラスクローラーウィスパー） [新品]

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

Whisper D-2kW uses two DC servomotors, controlled by an internal microprocessor, to directly drive the color scrolls. The velocity is controlled independently for each motor to ensure correct gel string tension and position.Fan operation is accessed via DMX channels and remotely controlled by the lighting console. Operational modes are set using the 5 DIP switches on the colour changer unit. When teamed with Compulite control consoles, unique scroller patching, special dark gel and frame setup functions are available in the Scroller Patch menu. The Compulite Whisper D-2kW colour changer is compatible with all control consoles that output DMX512 lighting control data.

■仕様
・Spot type: 2kw
・Height: 41.6cm (16.4")
・Width: 38.9cm (15.3")
・Depth: 7.4cm (2.9")
・Front aperture:26.5 (10.4")
・Weight: 3.15kg (6.9lb)
・End to end speed: 2.5 sec
・connectors: 4 Pin XLR Daisy Chain
・Power supply: 48 / 24VDC
・Current consumption: 0.7A @ 48V DC
・Max number of frames: 16

■Frame dimensions:
・Leader frame: 51.1 cm (20.1")
・Active: 39.6cm (15.6")
・Width: 27.4cm (10.8")
・Daisy Chain: 8 Units / PSU
