ROBE ROBIN Pointe [中古:#ITEM30437]

It’s very bright and super-fast with a sharp parallel beam that cuts through the air and across video with ease.

It can project a static or rotating glass gobo to produce precision in-air and surface images with an even focal plane. Tight or at full 20 degree zoom, the output is crystal clear and brilliant. Add in either rotating, 6 way linear or 8 way circular, prisms to create wide reaching effects across any set.

■特徴
・LIGHT SOURCE　Osram Sirius HRI 280W RO
・LIGHT OUTPUT　Beam mode: 9.870 lm, 82.400 lx @ 20 m; Spot mode: 5.150 lm, 90.000 lx @ 5 m
・ZOOM RANGE　2,5° - 10° Beam mode, 5° - 20° Spot mode
・EFFECTS　rotating and static gobo wheel, circular 8-facet and linear 6-facet prism

■■仕様
■SOURCE
・Lamp: Discharge short arc lamp with integrated reflector
・Approved model: Osram Sirius HRI 280 W RO
・Lifetime: Standard mode (280 W) - 2.000 hrs, Eco mode (230 W) - 3.000 hrs
・CRI: 75
・CCT: 7000 K
・Control: Automatic and remote on/off
・Ballast: Electronic

■OPTICAL SYSTEM
・Robe’s proprietary optical design
・Zoom range:
・2.5°-10° beam application
・5° – 20° spot application
・Output lens diameter: 110 mm
・Fixture total lumen output:
・Beam mode: 9.870 lm
・Spot mode: 5.150 lm
・Light output:
・Beam mode: 82.400 lx @ 20 m
・Spot mode: 90.000 lx @ 5 m

■DYNAMIC EFFECTS
・Colour wheel: 13 dichroic filters + white
・Rotating Gobo wheel: 9 rotating, indexable and replaceable "SLOT&LOCK" glass gobos + open
・Static Gobo wheel: 14 gobos + open
・Prism 1: 8-facet circular prism rotating in both directions at different speeds
・Prism 2: 6-facet linear prism rotating in both directions at different speeds
・Frost effect: Separate, variable
・Motorized zoom and focus
・Pre-programmed random strobe & pulse effects
・Dimmer: 0 - 100%

■CONTROL AND PROGRAMMING
・Setting & Addressing: ROBE Navigation System 2 (RNS2)
・Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC
・3-editable programs, each up to 100 steps
・Stand-alone operation
・Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2, sACN
・Wireless CRMX technology from Lumen Radio: On request
・DMX Protocol modes: 3
・Control channels: 24, 16, 30
・Pan/Tilt resolution: 8 or 16 bit
・Colour wheel positioning: 8 or 16bit
・Rotating gobo wheel positioning: 8 bit
・Gobo indexing & rotation: 8 or 16bit
・Static gobo wheel positioning: 8 bitt
・Frost: 8 bit
・Zoom: 8 or 16bit
・Focus: 8 or 16bit
・Dimmer: 8 or 16bit

■MOVEMENT
・Pan movement: 540°
・Tilt movement: 270°
・Controllable speed of Pan/Tilt movement

■ROTATING GOBOS
・Glass gobos: 9 rotating gobos
・Outside diameter: 15.9 mm
・Image diameter: 12.5 mm
・Thickness: 1.1 mm
・High temperature borofloat or better glass
・"SLOT&LOCK" system for easy replacement of gobos

■STATIC - BEAM GOBOS
・Aluminium wheel with fixed gobos: 10 gobos & 4 beam reducers
・THERMAL SPECIFICATION
・Maximum ambient temperature: 45°C (113°F)
・Maximum surface temperature: 90°C (194°F)

■ELECTRICAL SPECIFICATION AND CONNECTIONS
・Power supply: Electronic auto-ranging
・Input voltage range: 100-240 V, 50/60 Hz
・Power consumption: 470 W at 230 V / 50 Hz
・Power in connector: Neutrik powerCON
・DMX and RDM data in/out: Locking 3-pin & 5-pin XLR
・Ethernet port in/out: RJ45

■APPROVALS
・CE Compliant
・cETLus Compliant

■MECHANICAL SPECIFICATION
・Height: 575 mm – head in vertical position
・Width: 364 mm
・Depth: 250 mm
・Weight: 15 kg
・Ingress protection rating: IP20

■RIGGING
・Mounting points: 2 pairs of 1/4-turn locks
・2x Omega adaptors with 1/4-turn quick locks
・Universal operating position
・Pan and Tilt transport locks
・Safety cable attachment point
