ETC ColorSource PAR V Zoom（カラーソースパーV ズーム）

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

特徴

Compact on size, not feature set
An LED luminaire crafted by lighting experts with a proven history of quality, meet ColorSource PAR V Zoom. The 17-41 degree manual zoom eliminates the need for additional diffusion, and lets you change between spot and wash with a twist of the wrist. With a balanced mix of red, green, blue, indigo, and lime LEDs, and impressive brightness, this will become your new go-to fixture.

Color integrity
ColorSource PAR V Zoom is factory-calibrated to ensure consistency between today’s fixtures, and the ones you’ll use five years from now. The thermal management algorithms built into every ColorSource V fixture ensure that the colors you choose in rehearsal are the colors you get during the show.

17-41 degree zoom

The manual zoom control using the knob on the bottom of the fixture eliminates the need for additional diffusion.

A more sustainable rig
Lower Watts
Lower watts for more output means lower power consumption and increased luminaires per circuit. But, perhaps just as importantly, it means lower heat, which leads to quieter fans and quieter fixtures overall. ETC obsesses over every detail, ensuring that the fixture you buy today will still be lighting incredible shows for years to come.

Long, light life
The entire ColorSource PAR V Zoom fixture has an L70 rating of 54,000 hours. To put that in perspective, with an average per-day usage of three hours, seven days a week, you are looking at a lifespan of 50 years from one single fixture.

You’ll feel confident in ColorSource V lighting your stage for a long time to come. With an impressive warranty, 5-years on the fixture, 10-years on the array, and industry-leading 24/7/365 customer support, we’ll be here if you need us.

仕様

Source
LED details
34 Lumileds LUXEON
®
C LEDs
Max lumens
5007
Lumens per watt 33.4
L70 rating (hours to 70%
output)*
54,000 hours
Color
Colors used
Red, Green, Blue, Indigo , Lime
Color temperature range Color mixing
Calibrated array
Yes
Red shift
No
Optical
Beam angle range 17°–41°
Gate size
N/A
Aperture size
190 mm (7.48 in)
Pattern projection No
Pattern size
N/A
Camera flicker
control/Hz range
5,000 Hz (default) and 25,000 Hz (via
RDM
Control
Input method
5-Pin XLR, Multiverse wireless, and NFC
Protocols
DMX-512, RDM, City Theatrical
Multiverse, NFC
Modes (footprint) 5 modes, see page 6
RDM configuration
Yes
UI type
Seven-segment display, three-button
interface
Local control
Yes
Onboard presets Yes (12)
Onboard sequences Yes (5)
Onboard effects No
FixtureLink
Yes
Notes
15-bit virtual dimming engine
Wireless
Band
2.400–2.480 GHz
Range
100 m indoors, 500 m line of sight
(subject to conditions)
Max receivers
DMX: No limit
RDM: Varies by transmitter used
Multiverse SHoW Baby
®
: 585
Multiverse Transmitter: 5,000
Broadcast power 100 mW
Electrical
Voltage range
100–240 VAC 50/60 Hz
Input method
powerCON TRUE1 TOP power in
and thru
Inrush (first half-cycle)
120 V: 31 A
240 V: 66 A
Fixtures per circuit on
standard R20 breaker
6
(link up to 5 via Power Thru
connector)*
Note: TRUE1 connector rated for
20 A (120 V / 60 Hz) and
16 A (240 V / 50 Hz)
Wattage (typical)
120 V: 150 W
230 V: 148 W
Current draw
120 V: 1.27 A
230 V: 0.70 A
*Note: All measurements are for 120 V, 60 Hz. Results may vary in different regions.
Thermal
Ambient operating temp 0°C–40° C (32°F–104° F)
Fan (controllable)
Yes (yes)
Droop compensation Yes
Average dB
TBD dBA
BTUs/hour (120 V) 512
Physical
Materials
Cast and extruded aluminum
Color options
Black, white, silver, or custom color
Mounting options
Yoke
IP rating
IP20
Weight
4.45 kg (9.8 lb)
Included accessories
Yoke, power cable
Warranty
Fixture
5 years
LED array
10 years
Regulatory and Compliance
Approved regulatory
standards
cETLus Listed
Conforms to UL 1573
Complies to CSA C22.2 No. 166.0
CE & UKCA compliant
*Note: All LED sources experience some lessening of light output and some color
shift over time. LED output will vary with thermal conditions. In individual situations,
LEDs will be used for different durations and levels. This can eventually lead to
minor alterations in color performance, necessitating slight adjustments to presets,
cues or programs.
