Vari-Lite VL600 ACCLAIM PLE+（VL600 アッカリウム PLE+）／Black

概要

The VL600 Acclaim PLE+ is an ellipsoidal light designed specifically for larger theatrical spaces. The VL600 PLE+ is a 305W LED fixture with a multichromatic RGBL light engine that offers excellent key lighting for schools, theatres, and houses of worship, with over 15,000 lumens of output.

The VL600 Acclaim PLE+ works with Vari-Lite’s wide range of fixed and zoom lens tubes, ensuring there is a lens for any application. With the onboard four-blade manual shutter system, the VL600 PLE+ offers superior control to shape the light how you want it. Thanks to the optional size B metal gobo holder, designers can project depth and texture on stage, using the angle adjustment and manual focus to get the look just right. For applications where a low trim height is a challenge, the adjustable yoke allows the fixture to be positioned closer to the suspension point to give more headroom.

Thanks to onboard Ethercon connectivity, the VL600 Acclaim PLE+ can be controlled directly via sACN or Art-Net without a separate DMX gateway. The VL600 PLE+ is sold in black or white.

特徴

Multichromatic Light Engine RGBL
305W Max Wattage
15,500 Lumens of Output
Lockable continuous rotating gate and shutter assembly
Dual B size gobo/iris slot
Standard Vari-Lite lens tube configuration
Height adjustable yoke
Active fan controls and preset modes

仕様

Specifications
Due to continuous improvements and innovations, specifications may change without notice.
Engine only - 15,500
7100 K - 85
5600 K - 84
3200 K - 84
7100 K - Rf 77 / Rg 102
5600 K - Rf 78 / Rg 109
3200 K - Rf 78 / Rg 109
7100 K - 92
7100 K - 73
5600 K - 73
3200 K - 70
4 blade manual framing shutters, locking rotating gate
Source
LED
Multichromatic Light Engine - RGBL
Source Max Power Consumption
305 W
LED Refresh Rate
500 Hz to 4000 Hz
Dimming
Electronic 8-bit / 16-bit
Dimmer Curves
Square Law (Default), Linear, S -Curve
Strobe Speed
0 - 30Hz
Optical Performance
Output Lumens
CRI RA
Tm30
CQS
TLCI
Color System
Color Mixing
RGBL
Color Mixing Control
Open Source
Color Calibration
Selectable On/Off
Color Presets
40
Imaging
Shutter
DMX512-A (RDM), ArtNet, sACN
14 Channels
9 Channels
5 - Pin XLR Input and Thru, Ethercon Input and Thru
Advanced Feature local control
42.8 dB
35.5 dB
33.2 dB
0.0dB
Continuous (On) / Auto Ramping
Standard, Studio, Whisper
Hybrid sealed liquid and forced air system
Electrical
Max output Power Consumption
310 W
Power Connection
TrueOne Compatible - In / Thru
Power cable not included - input connector only
Input Voltage
100–240 VAC, 50 / 60 Hz
Standby Power
8.8 W
Data
Supported Protocols
DMX Modes
16-Bit
8-Bit
Data Connections
Manual Preset Mode
Noise Level / Fan Control
Standard Mode
Studio Mode
Whisper Mode
Silent Mode
Fan Mode
Fan Level Preset
Cooling System Type
Mounting
Yoke
Double clutch locking yoke >270° Swivel Yoke M12
(1/2") Centre hole
Fixture mounting/Hanging
orientation
Hanging - Floor - Side
Secondary Safety Wire Point 1 x Safety point located on rear of fixture housing
Safety Wire not included
Photometrics and IES Files
For IES files and photometric reports, please refer to the product page:
https://www.vari-lite.com/global/products/acclaim-led-ple-plus
(Base Level 21 dB @ 1 m (3.3
ft))

参照

■メーカーサイト
https://www.vari-lite.com/global/products/acclaim-ple-plus
