HIGHLITE Showtec ACT Profile 50 RGBAL（ショーテック ACT プロファイル 50 RGBAL） [34033]

概要

The Showtec ACT Profile 50 RGBAL is a 50 watt RGBAL COB LED ellipsoidal with high CRI, suitable for theatrical applications. It operates within a 14° - 32° manually adjustable zoom range and projects a hard-edge, precisely focused light. The ACT Profile 50 RGBAL features a manually and DMX controllable 0 - 100 % dimmer function and comes with 5 design gobos and a four-blade shutter system, allowing you to add the proper intensity of light where its needed.

特徴

Modified 150 W RGBAL COB LED ellipsoidal
Suitable for theatrical and studio applications
DMX dimmer function and manually controllable zoom
Five design gobos included
Hard edge, accurately focused field of light

仕様

Source
Light Source Type
LED
Light Source Quantity
1
Light Source Power
150 W
LED Colour Type
RGBAL
Refresh Rate
1200 Hz
Illuminance @ 2 m
1205 lx
Illuminance @ 3 m
536 lx
Illuminance @ 5 m
193 lx
Luminous Flux (Total)
220 lm
Luminous Flux (Red)
195 lm
Luminous Flux (Green)
271 lm
Luminous Flux (Blue)
113 lm
Luminous Flux (Amber)
107 lm
Luminous Flux (Lime)
234 lm
CRI
92
Minimum CCT
2700 K
Maximum CCT
10000 K
Optical
Beam Angle Minimum (Circular)
13 °
Beam Angle Maximum (Circular)
26 °
Zoom Type
Manual
Zoom Ratio
1:2
Control and Programming
Control Mode
DMX, Manual
DMX Channels
5, 8, 12
Protocols
DMX, RDM
Display
OLED
Dim Curve
Linear, Square, I-Square, S-Curve
Dimmer Resolution
16 bit
Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50/60 Hz
Power Consumption
55 W
Power Connector In
Power Pro Blue
Power Connector Out
Power Pro Grey
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P
Noise Level Maximum
31.9 dB
IP Rating
IP20 (indoor use only)
Housing
ABS, Aluminium
Colour
Black
Product Properties
Cooling
Convection/Axial fan
Rigging
Mounting Options
Bracket
Safety Attachment
Yes
Safety Eyes
1
Thermal Specifications
Maximum Ambient Temperature
45 °C
Included Items
Included Cables
Power Pro Cable
Included Accessories
Filterframe, Metal Gobo's (5x), Gobo Holder

サイズ

Mechanical Specifications
Length (mm)
430 mm
Width (mm)
168 mm
Height (mm)
293 mm
Weight
3 kg
