HIGHLITE Infinity TFLD-7 Floodlight（インフィニティ TFLD-7 フラッドライト） [200400]

概要

The Infinity TFLD-7 combines a compact, lightweight and versatile design with the already known custom designed 7 colour LED array and intelligent software to create the most sophisticated little floodlight possible. This custom 7 colour array will put out a white with consistently higher CRI value above 96 over the entire CCT range, and easily creates your specials with the built-in virtual scroller with 64 theatrical colours.
The calibration ensures a perfect blend of light throughout your theatre, stage or studio. Equipped with 7 different DMX modes, this luminaire is fully compatible with all the TS-260C7 and TCYC-7. Combining these 3 coloured luminaires in one setup creates the perfect match when light and colour quality are needed.

特徴

150 W lumiled 7 colour LED engine using custom designed array
CRI > 96 Consistently on full CCT range
LED colour linearity and temperature drift compensation
Optics Colour Shift compensation
Colour wheel with 64 spectrum matching Filter gels

仕様

Source
Light Source Type
LED
Light Source Quantity
7
Light Source Power
150 W
LED Colour Type
RGBCALDB
Life Expectancy
30000 h
Refresh Rate (Max.)
1 kHz
Luminous Flux (Total)
3000 lm
CRI
96
Minimum CCT
2000 K
Maximum CCT
8000 K
Control and Programming
Control Mode
DMX, Manual
DMX Channels
1, 5, 6, 10, 20
Protocols
DMX, RDM
Display
LCD
Fan mode
Yes
Dim Curve
Linear, Square, I-Square, S-Curve
Dimmer Resolution
16 bit
Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz
Colour System
Colour Wheel CMY+CTO
Electrical Specifications and Connections
Power Supply
100-240 V AC 50/60 Hz
Power Consumption
160 W
Power Connector In
powerCON Blue
DMX Connector
XLR 3P In/Out, XLR 5P In/Out
DMX Connector In
XLR 3P, XLR 5P
DMX Connector Out
XLR 3P, XLR 5P
IP Rating
IP20 (indoor use only)
Housing
Aluminium
Colour
Black
Product Properties
Cooling
Active
Thermal Specifications
Maximum Ambient Temperature
40 °C
Maximum Surface Temperature
55 °C
Minimum Operating Temperature
-10 °C
Included Items
Included Cables
powerCON cable

サイズ

Mechanical Specifications
Length (mm)318 mm
Width (mm)136 mm
Height (mm)239 mm
Weight5.34 kg
