CIty Theatrical Eluxtra 4-in-1 LED Strip Light, 24V, Outdoor/Waterproof, RGB + Amber（Eluxtra 4-in-1 LEDストリップライト 24V アウトドア／ウォータープルーフ RGB + アンバー） [wp-RGBA-5050-60-24V-5m]

Eluxtra™ 4-in-1 LED Strip Light, 24V, outdoor is UL Listed and features 60 LEDs per meter. Eluxtra 4-in-1 LED Strip Lights are 24V and allow you to run a full reel without any visible voltage drop or corresponding color changes along the length of the run. Mix all four diodes together to create a vast spectrum of vibrant colors for outdoor LED tape installations.

概要

Eluxtra 4-in-1 LED Strip Light, 24V, Outdoor is a high quality and extremely dependable strip light that is an ideal lighting solution for utilizing color in dynamic set designs, eye-catching displays, and so much more. Eluxtra 4-in-1 LED Strip Light, 24V, Outdoor is sold in 5-meter reels or in cut-to-order lengths. Color variations include:

RGB + 2700K White
RGB + 6500K White
RGB + Amber
Eluxtra 4-in-1 LED Strip Light, 24V, Outdoor is IP65-rated waterproof to protect against dust, splashes, and rain. Additional Eluxtra 4-in-1 LED Strip Light options are available with an IP20 rating for indoor installations.

Eluxtra represents the next evolution in LED tape light technology. It is engineered to enhance performance and simplify installation for professionals across many industries. Delivering consistent performance, simplified wiring, and vibrant colors, Eluxtra makes it easier for lighting designers to achieve their goals with minimal complexity. All configurations are UL Listed and feature 60 LEDs per meter.

Eluxtra is available through City Theatrical and Environmental Lights.

For detailed specifications on Eluxtra 4-in-1 LED Strip Light, click on the part numbers below to view each cut sheet.

仕様

Cutting Increment 100.00 mm (3.94 in)
LED Spacing 16.7mm (0.657 in)
Lead Detail 200mm (7.874 in) long flat cable on both ends, stripped 10mm and tinned
Backing Color White (with clear waterproof silicone coating)
Output
Color Red, Green, Blue, Amber
Color Temperature N/A
Brightness 115/340/65/110 lm/m
Beam Angle 120°
Electrical
Operating Voltage 24VDC
Current (A/5m) 3A
Power Consumption (w/m) 14.4 w/m
Power Consumption (w/ft) 4.4 w/ft
Density (LEDs/m) 60 LEDs/m
LED Chip Size 5050
Product Information
Use Environment Outdoor
Ambient Temperature -20° C to 40°C
Dimmable Fully Dimmable
Average Life 50,000 hours
Warranty Five years limited
IP Rating IP65
Compliance UL, RoHS

サイズ

Length 5m
Width 12mm
Height 2 mm

参照

■メーカーサイト
https://www.citytheatrical.com/products/electronics/eluxtra/eluxtra-4-in-1-led-strip-light-24v-outdoor
