CHAUVET Professional onAir Flex Drive 2（オンエアフレックスドライブ 2）

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

概要

onAir Flex Drive 2 is an LED Driver ideal for TV studios seeking simple and impactful on-camera looks with integrated power supply and driver for a one-box modular solution. onAir Flex Drive 2 features 24v to allow longer run lengths for set pieces and light boxes, and 8 channels of output for complete flexibility with a choice of tapes and lengths. It also features adjustable PWM, making it ideal for broadcast compatibility. With two outputs, onAir Flex Drive 2 supports RGBW or generic 4-channel control for up to 350W of total power and assisted convection cooling perfect for studio environments. To ease installation, onAir Flex Drive 2 also features DMX 5pin and Phoenix connector for installation support.

特徴

TV focused 24 VDC constant voltage LED Driver with integrated power supply
Adjustable PWM makes this product ideal for broadcast compatibility
Two outputs support RGBW or generic 4-channel control for up to 350W of total power
Assisted convection cooling utilizes a quiet fan for studio environments
Built in overcurrent and short circuit protection with indicator LEDs
RDM supported for remote device management
Scalable rack mount system, two per 1U space
DMX 5pin and Phoenix connector for installation support

仕様

Dynamic Effects
Standalone Color Mixing: Yes
Built-in Automated Programs: Yes

Construction / Physical
Exterior Color: Black
Housing Material: Steel
Rackmount: 1U

Connections
Power Connection: Edison (Local) plug to Neutrik powerCON TRUE1 Compatible
Power Input: Seetronic Powerkon (powerCON Compatible)
Power Output: Seetronic Powerkon (powerCON Compatible)
Device Outputs (5-pin Phoenix Connector): 2
Physical Linking Per Port: 2 RGBW Tape
Data Connectors: 5-pin XLR, 3 Pin Phoenix Connector
Cable Length (power): 1.5 m
Total Max Cable Extension Length Per Port: 30.48m 16 AWG

Control
Control Protocol: DMX
DMX Channels: 8 or 10
Modes/Personalities: RGBW, RGBW+D
Total Output Power (Per Port): 200 W
Total Output Power (Total): 350 W

Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 2 units @ 120 V; 5 units @ 208 V; 5 units @ 230 V;
Power and Current: 400 W, 3.34 A @ 120 V, 60 Hz
Power and Current: 400 W, 1.93 A @ 208 V, 60 Hz
Power and Current: 400 W, 1.74 A @ 230 V, 50 Hz

Certifications / Qualifications
CE
US Safety: UL 8750
Canadian Safety: CSA C22.22 No. 250.13
IP Rating: IP20, dry location
Temperature (Ambient): -20 °C to 45 °C

What's Included
onAir Flex Drive 2
Neutrik powerCON TRUE1 power cord
