Chauvet Professionall onAir Panel 3 IP（オンエアパネル 3 IP）

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

概要

onAir Panel 3 IP is a rugged IP65 full-spectrum low-profile 1×3 format LED soft light capable of facing all of the elements, indoors or out. Ready to go on location for any broadcast setting, onAir IP Panel 3 features a superior quality of white light with high CRI/TLC and TM-30 scores, a smooth 16-bit dimming curve and +/- green adjustment, an emulated redshift, the ability to produce a pop of color to achieve the exact look you are aiming to create, along with built-in customizable effects accessible from the onboard control menu. Easily switch mounting options from Jr Pin to Omega Bracket. Drop-in slot for diffusers and intensifier filters ensures ease of use when changing accessories. Adjustable PWM ensures camera-ready use. An optional 28 VDC input via 3-pin XLR powers the fixture from an external battery pack to add increased flexibility for all of your remote needs. DMX, RDM, CRMX, Art-Net, sACN, and onboard control options make for flexible operation.

特徴

Full-spectrum LED linear format soft light panel style fixture for broadcast, film, and special events
IP65 rating for all weather use indoors or out.
Linear color temperature presets from 2800 K to 8000 K with high CRI and CQS
Virtual color wheel with color matched to popular gel colors
+/- Green adjustment and emulated red-shift via DMX or on-board control
RDM (Remote Device Management) and CRMX Wireless Control for added flexibility
Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
Virtually silent operation for use in studio applications
Ultra-smooth 16-bit dimming curves and speeds to complement any lighting scheme.
Easily switch mounting options from jr pin to omega bracket
Drop-in slot for diffusers and intensifier filter (sold separately)
Rugged design for years of rough use in the most extreme conditions.
Easy to use on-board control with full access to all the features of the fixture without the need for a dedicated controller.
USB port for fixture software updates
28 VDC power input via 3-pin XLR to power the fixture from an external battery pack

仕様

Optical
Light Source: 120 LEDs (tri-color RGB) 1.5 W, (282 mA), 50,000 hours life expectancy.
Light Source: 120 LEDs (WW) 0.5 W, (113 mA), 50,000 hours life expectancy.
Color Temperature (range): 2800 to 8000 K
Color Temperature (at full): 5527K
CRI (3200 K): 91.2
Beam Angle (No Optics): 111.3°
Beam Angle (Light Filter): 96.7°
Beam Angle (Medium Filter): 97.8°
Beam Angle (Heavy Filter): 108.2°
Beam Angle (Intensifier Filter): 74.4°
Field Angle (No Optics): 153.9°
Field Angle (Light Filter): 149°
Field Angle (Medium Filter): 158.4°
Field Angle (Heavy Filter): 162°
Field Angle (Intensifier Filter): 135.2°
Lumens (No Optics): 8080
Lumens (Light Filter): 6896
Lumens (Medium Filter): 6317
Lumens (Heavy Filter): 5964
Lumens (Intensifier Filter): 5498
Illuminance (No Optics): 143 lux @ 5 m
Illuminance (Light Filter): 134 lux @ 5 m
Illuminance (Medium Filter): 110 lux @ 5 m
Illuminance (Heavy Filter): 91 lux @ 5 m
Illuminance (Intensifier Filter): 141 lux @ 5 m
Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

Dynamic Effects
Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0 to 20 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Dim Curves: 4
Built-in Automated Programs: Yes

Connections
Power Connection: Edison (Local) plug to Seetronic Powercon IP65
Power Input: Seetronic Powercon IP65
Power Output: Seetronic Powercon IP65
Power Input: 28 VDC, 3-pin IP65 XLR
Data Connectors: 5-pin IP65 XLR, Seetronic etherCON® Compatible
Cable Length (power): 1.5 m
Software Connection: Type-C USB

Control
Control Protocol: Art-Net, sACN, DMX, WDMX, CRMX, RDM
DMX Channels: 1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended
Art-Net Channels: 1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended
Modes/Personalities: 14 personalities (1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended)

Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 8 units @ 120 V; 14 units @ 208 V; 16 units @ 230 V
Power and Current: 167 W, 1.392 A @ 120 V, 60 Hz
Power and Current: 160 W, 0.823 A @ 208 V, 60 Hz
Power and Current: 157 W, 0.747 A @ 230 V, 50 Hz

Certifications / Qualifications
CE, MET, FCC, UKCA
IP Rating: IP65, temporary outdoor use, with pressure equalizing M12 GORE valve
Temperature (Ambient): -20 °C to 45 °C

What's Included
onAir Panel 3 Slim IP
Seetronic Powercon IP65 power cord
Omega bracket with mounting hardware
onAir Panel 3 IP Medium Diffusion Filter
TV Junior Spigot
