ChamSys GeNetix 10Scene Wall Plates（ジェネティクス 10シーンウォールプレート）

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

The 10Scene Wall Plate features ten 10Scene trigger buttons, with dual colour LED status indication.

Connect 10Scene wall plates directly to the QuickQ Rack or to the SnakeSys Gateway interface, where it can then integrate with any MagicQ or QuickQ system for remote Scene activation.

Supplied in a dual pack containing two wall plates available in either EU or US back box fit and with two black and two white clip on faceplates to go with.

特徴

Using standard Cat 5E cable for connectivity
Connect direct to QuickQ Rack or 10Scene Gateway, no power injectors required
Easy to daisy chain – up to ten 10Scene wall plates per chain
Long distance – one 10Scene at 1000 metres or five 10Scenes in a chain at 300m
Supplied in a dual pack containing 2 wall plates, 2 white faceplates and 2 black faceplates
Available in EU (Part no:300-055) or US (Part no:300-054) single gang backbox fit

Features
• Uses standard Cat 5E cable for connectivity
• Connect directly to MagicQ or QuickQ Rack & DIN products,
nopower injectors required
• Easy to daisy chain – up to ten 10Scene wall plates per
chain
• Long distance – one 10Scene at 1000 metres or fi ve
10Scenes in a chain at 300m
• Supplied in a dual pack containing 2 wall plates, 2 white
faceplates and 2 black faceplates
• Available in EU/UK or US single gang backbox fi t

仕様

Hardware Specifi cations:
• 10Scene Buttons: 10
• Dual Colour Red/Blue buttons: Yes
• Powered via 10Scene Protocol: Yes
• Max Number of 10Scene wall plates per chain: 10
• Compatible with MagicQ/QuickQ Rack & DIN: Yes (In-built
connectors or via Gateway)
• Compatible with both MagicQ & QuickQ systems: Yes (via
Gateway)
