HIGHLITE Showtec Titan Strobe FLEX FX（ショーテック タイタン ストロボフレックス FX） [40305]

特徴

The Showtec Titan Strobe FLEX FX is a set of 8 high-power LED strobes and a dedicated controller. Each individual pod has a powerful cold white 100-watt COB LED for strobing and a ring of 12 individually controllable 2-watt RGBW LEDs. The integrated RGBW LEDs allow you to create unique full-colour LED ring effects. The powerful LED light source combined with a strobe functionality allows you to use the Titan Strobe FLEX FX as a strobe light with bright colour effects. It uses a Fresnel lens to create the optimum beam angle. The light effect can be controlled via DMX/RDM, Art-Net, sACN and Master/Slave, but can also run in stand-alone mode with several built-in programs.
The strobe pods have a special mounting bracket with 4 holes at a 45-degree angle, so you don’t have to detach the pod from it to drill through the holes to mount it. The bracket also has a 12.5 mm hole, while the controller has two 12.5 mm holes and an M10 threaded insert for attaching a clamp. You can also attach a quick lock bracket to the controller and pods. The pods and controller have a robust IP65-rated aluminium enclosure and are ready for outdoor shows. Dedicated 4x 2.5 m and 4x 5 m cables with control signals and power are included. Additional dedicated cables of various lengths are available separately (maximum length allowed: 30 m).

仕様

Specifications
Source
Light Source Type
LED
Light Source Power
100 W
LED Colour Type
CW, RGBW
Optical
Beam Angle (Circular)
53 °
Control and Programming
Control Mode
Art-Net, Built-in Program, DMX, Manual
Protocols
Art-Net, DMX
Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50/60 Hz
Power Consumption
740 W
Power Connector In
powerCON TRUE1
Power Connector Out
powerCON TRUE1
DMX Connector
XLR 5P In/Out
DMX Connector In
XLR 5P
DMX Connector Out
XLR 5P
Data Connector
etherCON In/Out
Data Connector In
etherCON
Data Connector Out
etherCON
Mechanical Specifications
Height (mm)
195 mm (7.677″)
Width (mm)
221 mm (8.701″)
Depth (mm)
115 mm (4.528″)
Weight
1.61 kg (3.549 lb)
Controller Height
103 mm (4.055″)
Controller Width
171 mm (6.732″)
Controller Depth
373 mm (14.685″)
Controller Weight
3.65 kg (8.047 lb)
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black
Product Properties
Cooling
Forced Convection
Rigging
Mounting Options
Clamp, Quick-Lock
Safety Attachment
Yes
Thermal Specifications
Maximum Ambient Temperature
40 °C (104 °F)
Minimum Ambient Temperature
-5 °C (23 °F)
Included Items
Included Cables
Flex Cable 2,5M, Flex Cable 5M, Power Pro True Cable
Included Rigging
1x Quick-Lock Bracket
Product Compliance
Energy efficiency class
T/B/D

参照

■メーカーサイト
https://www.highlite.com/en/products/new-products/40305-titan-strobe-flex-fx.html
