HIGHLITE Infinity Raccoon Junior P7/4（インフィニティラクーンジュニア P7/4） [200501]

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

特徴

The Raccoon P7/4 is a high-brightness, high-CRI, IP65-rated Par, intended for applications where both brightness and quality are of high importance, especially rental applications and situations that demand a high light output. It has 7 extremely bright LEDs that have four colours each: red, green, blue, and mint. You can switch between maximum brightness and maximum colour-rendering quality (high CRI) mode.

The fixture offers top-of-the-line control options. The core technology of the Raccoon series is the calibrated colour engine, which guarantees outstanding colour quality and stability. By embedding the xy control mode technology, the Raccoon series ensures consistent and accurate colours at any time. The sophisticated software engine, developed in Europe, ensures an exceptionally stable colour output under all circumstances. Thanks to the (LED) temperature compensation, which is monitored continuously by the software, any visible colour shifting during the operation is prevented.

We use the same calibration standards as the Infinity Signature series, so the fixtures are highly consistent in colour. Five different internal dimmer curves are available through the easy-to-use menu system, including a Tungsten shift simulation that works even with a colour filter applied! It can take care of CCT, RGB, and Lee filters internally.

Besides xy mode, control through regular DMX, RDM, and Manual is also possible. The PWM frequency is adjustable between 640 Hz and 25 kHz, ensuring flicker-free camera images. Basic settings, like PWM and dimmer curve, can be copied among Raccoon fixtures in the same network to guarantee identical behaviour. Sturdy 5P XLR DMX and Power Pro True power connectors ensure reliable connections and IP65 compliance. With its stylish housing and accessories like barndoors, a top hat, filter frames, and diffusion filters, the Raccoon series poses an ultra-flexible competitor for high-end pars.

仕様

Specifications
Source
Light Source Type
LED
Light Source Quantity
7
Light Source Power
15 W
LED Colour Type
R, G, B, M
Life Expectancy
30000 h
Refresh Rate (Max.)
25 kHz
Illuminance @ 2 m
12250 lx
Illuminance @ 3 m
5445 lx
Illuminance @ 5 m
1960 lx
Luminous Flux (Total)
3459 lm
Luminous Flux (Red)
765 lm
Luminous Flux (Green)
1148 lm
Luminous Flux (Blue)
325 lm
Luminous Flux (Mint)
1744 lm
CRI
86
Minimum CCT
2000 K
Maximum CCT
8000 K
Optical
Beam Angle (Circular)
10 °
Control and Programming
Control Mode
DMX, Manual, Static Dimmer
DMX Channels
1, 3, 8, 10, 12
Protocols
DMX, RDM
Display
OLED
Dynamic Effects
Dimmer
0-100 %
Strobe
0-25 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50/60 Hz
Power Consumption
75 W
Power Connector In
Power Pro True
Power Connector Out
Power Pro True
DMX Connector
XLR 5P In/Out
DMX Connector In
XLR 5P
DMX Connector Out
XLR 5P
Mechanical Specifications
Length (mm)
184 mm (7.244″)
Width (mm)
232 mm (9.134″)
Height (mm)
285 mm (11.221″)
Weight
4 kg (8.818 lb)
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black
Product Properties
Cooling
Convection
Rigging
Mounting Options
Clamp, Quick-Lock
Thermal Specifications
Maximum Ambient Temperature
45 °C (113 °F)
Minimum Operating Temperature
-20 °C (-4 °F)
Included Items
Included Cables
Power Pro True Cable
Included Rigging
Quick-Lock Bracket
