SGM i-2 UVA 365
商品詳細
The i-2 UVA 365 is a powerful ultraviolet wash figure with a narrow beam, suitable for any application requiring high output over medium and long distances. The UV LED engine has a 365 nanometer dominant wavelength for maximum invisible light with a minimum of visible emissions. The optics have been designed to condense and distribute an impressive amount of UV light with minimal spill.
Optical Data
LED expected lifetime (L70) 17,000 hours
Lightsource 63 x UVA LEDs
Native lens options 8.5°
Optional honeycomb Internal
Photometric
Native beam angle(s) 8° (with 8.5° lens)
Native field angle(s) 19°
Physical
Color options Black - RAL 9004
Custom color - Any RAL
White - RAL 9010
Effective Projected Area 0.96 Square ft
IK rating IK05
IP class IP65
Material Aluminium
Net dimensions L x H x W 334 x 223 x 105 mm
Net dimensions L x H x W (inches) 13.2 x 8.8 x 4.1 inches
Features
Color calibration Single-unit color
Dehumidifier Head
Power / DMX indicator Head
Tilt 0 - 190°
Programming and Control
16-bit control Dimmer
Cabled DMX 5 pin XLR input/output
DMX channels 1, 2 or 4
DMX modes 4
Protocol USITT DMX512A
RDM ANSI E1.20
Setting and addressing OLED graphical display / 4 buttons
RDM ANSI E1.20
Standalone mode
Installation
Mounting point 2 quarter-turn locking points for one Omega bracket
Orientation Any
Rigging possibilities Floor stand (included) or hanging (Omega clamps included)
Safety features Bottom mount for safety wire
Minimum distance to combustible materials: 0.3 meter (11 in).
Thermal
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 98 %
Included items
Included items Mounting bracket (incl. screws)
1 Omega bracket with quarter-turn fasteners
Safety instructions and installation quick guide
Conforms To
CE - 2014/30/EU: EMC Directive EN 55015
EN 61547
EN 61000-3-2
EN 61000-3-3
EN 55032
EN 55035
CE - 2014/35/EU: Low Voltage Directive EN 60598-1
EN 60598-2-17
EN 62471
EN 60529
RoHS2 Directive 2011/65/EU
UL UL Std. 1573
Certified To
CSA CSA-E598-2-17-98, Ed: 1
CSA E60598-1, Ed: 3
■メーカーサイト
https://sgmlight.com/products/i%C2%B72-uva-365
