SGM Q-2 W

The Q-2 W is a compact and lightweight flood/blind/strobe with fast response, and controllable segments for pixel mapping applications. Sharing some of the key features of the Q-7 W, like wide angle lighting coverage, and a powerful strobe effect, the Q-2 W also includes the benefits of 12-segment pixel mapping control and low power consumption. Because of its efficiency, small size, and easy rigging options, the Q-2 W is a must-have flood/blind/strobe for any rental company, touring production, or corporate event.

仕様

Specification
Optical Data
LED expected lifetime (L70) 50,000 hours
Lightsource 432 x cool white LEDs (5,700K)
Native lens options 110°
Optional filters Extra medium angle soft diffusion, Q, external
Extra wide angle soft diffusion, Q, external
Elliptical horizontal effect, Q, external
Elliptical vertical effect, Q, external
Photometric
Average CRI (CTC) 83
Color temperature 5700K
Efficacy 114 lm/W
Light output all LEDs on 22976 lm
Lumen per kilogram 3829 lm / Kg
Lux @ 10m 82 lux
Lux @ 3m 907 lux
Lux @ 5m 326 lux
Native beam angle(s) 112° (with 110° lens)
Native field angle(s) 152°
Physical
Color options Black - RAL 9004
Custom color - Any RAL
White - RAL 9010
Effective Projected Area 0.96 Square ft
IK rating IK05
IP class IP65
Lens material Tempered glass front
Material Aluminium
Net dimensions L x H x W 334 x 223 x 105 mm
Net dimensions L x H x W (inches) 13.2 x 8.8 x 4.1 inches
Net weight 6 kg (13.2 lbs)
Features
Color calibration Single-unit color
Dimming 2 Smooth fade in, DMX-controllable curves: gamma corrected, and linear
Filters Optional external spread angle filters (requires Accessory Holder)
LED panel 12 individually controllable segments
Strobe Ultra-high-speed strobe effects
Pixel strobe feature (up to 12 segments)
Tilt 0 - 190°
Electrical
Electrical protection Overload protection
Input voltage, nominal 100 - 277 VAC; 50 / 60 Hz
Max inrush current 230VAC 75 A
Max power consumption 265 W
Power factor 0.96 PF (230 V)
Power Supply Unit Inbuilt IP 67 Auto-ranging electronic switch-mode
Standby power consumption 5 W
Programming and Control
16-bit control Dimmer
Cabled DMX 5 pin XLR input/output
DMX channels 1, 3, 6, 12, 14 or 24
DMX modes 6
Protocol USITT DMX512A
RDM ANSI E1.20
Setting and addressing OLED graphical display / 4 buttons
RDM ANSI E1.20
Standalone mode
Standalone mode Quick Color
Up to 24 programmable scenes
Connections
DMX data in/out 2 IP65 XLR 5-pin cables 0.5m (permanently wired)
Power Power cable 1 meter with bare ends (permanently wired)
Installation
Mounting point 2 quarter-turn locking points for one Omega bracket
Orientation Any
Rigging possibilities Floor stand (included) or hanging (Omega clamps included)
Safety features Bottom mount for safety wire
Minimum distance to combustible materials: 0.3 meter (11 in).
Thermal
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 98 %
Temperature range, operating -40°C to 50°C
Temperature range, operating max 50 °C
Temperature range, operating min -40 °C
Temperature range, start-up -20°C to 50°C
Temperature range, storage -40°C to 80°C
Thermal protection Automatic overtemperature protection
Total heat dissipation, max power 904.2 BTU per hour
Total heat dissipation, standby 17.1 BTU per hour
Included items
Included items Mounting bracket (incl. screws)
1 Omega bracket with quarter-turn fasteners
Safety instructions and installation quick guide
Conforms To
CE - 2014/30/EU: EMC Directive EN 55015
EN 61547
EN 61000-3-2
EN 61000-3-3
EN 55032
EN 55035
CE - 2014/35/EU: Low Voltage Directive EN 60598-1
EN 60598-2-17
EN 62471
EN 60529
RoHS2 Directive 2011/65/EU
UL UL Std. 1573
Certified To
CSA CSA-E598-2-17-98, Ed: 1
CSA E60598-1, Ed: 3
