SGM Q-7 W

The Q-7 W has defined a new level of power, accuracy, and flexibility in the lighting world. Together with the Q-7 RGBW, these fixtures are well-known as the most versatile strobe lights on the market. At the same time, the Q-7 W is also a bright audience blinder, a low-profile flood light, and an accurate wide-angle luminaire. It offers an excellent performance in any conditions for touring, events, theatrical productions, architectural installs, or corporate shows.

仕様

Specification
Optical Data
LED expected lifetime (L70) 50,000 hours
Lightsource 1,000 x cool white LEDs (5,700K)
Native lens options 110°
Optional filters Extra medium angle soft diffusion, Q, external
Extra wide angle soft diffusion, Q, external
Elliptical horizontal effect, Q, external
Elliptical vertical effect, Q, external
Photometric
Average CRI (CTC) 82
Color temperature 5700K
Efficacy 99 lm/W
Light output all LEDs on 48274 lm
Lumen per kilogram 5960 lm / Kg
Lux @ 10m 166 lux
Lux @ 3m 1839 lux
Lux @ 5m 662 lux
Native beam angle(s) 116° (with 110° lens)
Native field angle(s) 156°
Physical
Color options Black - RAL 9004
Custom color - Any RAL
White - RAL 9010
Effective Projected Area 1.72 Square ft
IP class IP65
Lens material Tempered glass front
Material Aluminium
Net dimensions L x H x W 497 x 268 x 122 mm
Net dimensions L x H x W (inches) 19.6 x 10.6 x 4.8 inches
Net weight 8.1 kg (17.9 lbs)
Features
Color calibration Single-unit color
Dimming 2 Smooth fade in, DMX-controllable curves: gamma corrected, and linear
Filters Optional external spread angle filters (requires Accessory Holder)
LED panel 4 individually controllable segments
Other LED frequency control, display selectable
Strobe Ultra-high-speed strobe effects
Intensity, Duration, Rate and FX control channels
Pixel strobe feature (up to 4 segments)
Tilt 0 - 190°
Electrical
Electrical protection Overload protection
Input voltage, nominal 208 - 240 VAC; 50 / 60 Hz
Max inrush current 230VAC 45 A
Max power consumption 485 W
Power factor 0.99 PF (230 V)
Power Supply Unit Auto-ranging electronic switch-mode
Standby power consumption 8 W
Programming and Control
16-bit control Dimmer
Cabled DMX 5 pin XLR input/output
DMX channels 1, 4, 6 or 8
DMX modes 5
Protocol USITT DMX512A
Wireless DMX (LumenRadio)
RDM ANSI E1.20
Setting and addressing OLED graphical display / 4 buttons
RDM ANSI E1.20
RFID
Standalone mode
Standalone mode Quick Color
Standalone mode programmable via RFID
Up to 24 programmable scenes
Wireless DMX Lumen Radio with RDM
Connections
DMX data in/out 2 IP65 XLR 5-pin cables 0.5m (permanently wired)
Power Power cable 1 meter with bare ends (permanently wired)
Installation
Mounting point 2 x 2 quarter-turn locking points for one or two Omega brackets
Orientation Any
Rigging possibilities Floor stand (included) or hanging (Omega clamps included)
Safety features Bottom mount for safety wire
Minimum distance to combustible materials: 0.3 meter (11 in).
Thermal
Cooling Active, Forced Air, Temperature-regulated
Humidity (max.) 98 %
Temperature range, operating -40°C to 50°C
Temperature range, operating max 50 °C
Temperature range, operating min -40 °C
Temperature range, start-up -20°C to 50°C
Temperature range, storage -40°C to 80°C
Thermal protection Automatic overtemperature protection
Total heat dissipation, max power 1654.8 BTU per hour
Total heat dissipation, standby 27.3 BTU per hour
Included items
Included items Wireless DMX antenna
Mounting bracket (incl. screws)
2 Omega bracket with quater-turn fasteners
Safety instructions and installation quick guide
Conforms To
CE - 2014/30/EU: EMC Directive EN 55015
EN 61547
EN 61000-3-2
EN 61000-3-3
EN 55032
EN 55035
CE - 2014/35/EU: Low Voltage Directive EN 60598-1
EN 60598-2-17
EN 62471
EN 60529
RoHS2 Directive 2011/65/EU
UL UL Std. 1573
Certified To
CSA CSA-E598-2-17-98, Ed: 1
CSA E60598-1, Ed: 3
