Rosco Braq Cube 4C（ブラックキューブ 4C）

特徴

小さなサイズがキーポイント：他の器具で駄目でも、Blaq Cubesなら大丈夫！たった5インチという小さな立方体の中に収納された空前100ワットのカラーミキシング発光源を持つBlaq Cubes® 4C！その驚くばかりの小さなサイズにもかかわらず、The Black TankデザインのBlaq Cube®は、従来の全体照明を補ってあまりある照明を発光し、放送スタジオでやステージや撮影現場や商業施設でご利用いただけます。業界No.1のRGBWクワッド対応チップエミッタを備えたBlaq Cube®4Cは、簡単なボタン操作で、鮮明色、中間色の、または淡い色調といった豊かなカラーパレットを作りだします。ハイクオリティエミッタを備えたBlack Cube®4Cは、他のカラーミキシング照明によく見られるアンバーがかった妥協の白よりも上質な「本物の白色」を作り出す能力を備えています。シングルチップオプティックが、マルチカラーの陰影を解消し、デザイナーの意のまま、完全にブレンドされた明瞭で安定したカラーウオッシュを作り出します。

仕様

LED:

7 x 12W Osram Ostar multi-chip

Output:

4C: 1800 Lumens (no lens)
4CA: 1710 Lumens (no lens)

Lumen Maintenance:

80,000 hours B10 L70 at 25°C
(LM79-08 Standard)

Color Range:

4C: Red/Green/Blue/White (6500K)
4CA: Red/Green/Blue/Amber

Operation:

DMX: 8 or 16 bit DMX512
Manual: Full Text LCD user interface sets color output

Input Voltage:

90 - 240 VAC 50/60Hz

Power/AC Input:

Neutrik Powercon

Data:

5-pin XLR Male, 5-pin XLR female – DMX

Power Consumption:

100 Watts at maximum output

Operating Temperature:

-13° to 113° F (-20° to 45° C)

Humidity:

0 - 95% non-condensing

Dimensions:

5in x 5in x 5.3in (127mm x 127mm x 135mm)

Weight:

3.5 lbs (1.6 kg)

Housing:

Powder coated aluminum extrusion (1/8 in wall)

Approvals and Listings:

FCC Class A Radiated and Conducted
ETL / UL Standards 1573 and 8750
cETL / CSA C22.2#166-M1983
CE
RoHS Compliant
IP20 Rated



Dry locations only



Features and Benefits:

Powerful, quad-chip, RGBW or RGBA LED emitters blend light without shadow fringing
RGBW color mixing offers a dramatic, saturated palette that is balanced with a subtle, nuanced range of tints and accent colors
RGBA color mixing offers richly saturated colors and full spectrum, warm white light color temperatures
Optional "Filament Mode" mimics the delayed blackout glow of an incandescent lamp
Low 100W power consumption allows more than 20 fixtures on a single 20A circuit
No expensive power supply unit or ballast required. Directly connect 90-240 VAC mains power
Comes with a complete spread lens set including: 20° spot, 40° medium and 60° wide flood
Power Cord configurations include:
8-ft AWG16 cord with Neutrik Powercon and 3-prong Edison ends
No cord
Optional Power Cord Accessories include:
8-ft AWG16 cord with Neutrik Powercon, 3-prong Edison ends, and an in-line switch
8-ft AWG16 cord with Neutrik Male/Female ends (Powercon Pass-Thru)
Flicker free DMX dimming (0 ~ 100%) and control
Intuitive, full text LCD panel for manual operation
Compact design suitable for mounting in small spaces or installations with low ceilings
Track lighting mounting adapters available for many common track brands or with our fully integrated Rosco Track.
Auto temperature sensing with fault detection and protection
ETL/CE listed


Product Number

515 90100 1014

Braq Cube® 4C w/Power Cord - Black

515 90100 2014

Braq Cube® 4C w/Power Cord - White

515 90100 1114

Braq Cube® 4C No Power Cord - Black

515 90100 2114

Braq Cube® 4C No Power Cord - White

515 90100 1040

Braq Cube® 4CA w/Power Cord - Black

515 90100 2040

Braq Cube® 4CA w/Power Cord - White

515 90100 1140

Braq Cube® 4CA No Power Cord - Black

515 90100 2140

Braq Cube® 4CA No Power Cord - White
