Robe T32 Cyc（T32 サイク）

Are your productions being spoilt by poor cyclorama lighting? Are they not bright enough? Don‘t reach high enough? Are they poor-performing adaptations of other luminaires? It‘s time to change your cyclorama lighting from an eyesore into an eye stunner!

特徴

Light source
16x 40W MSL™ RGBBAL LED multichips

Light output
up to 17.565 lm, Cpulse™ special flicker free management for HD and UHD cameras, ready for 8K and 16K

Field Angle
Asymmetrical field angle 85° x 45°, Opti-6™ - A 6:1 height-to-distance ratio

Effects
VertiSpot™ - Unique, motorised vertical crossover point control for superior blending and vertical output variance (patented)

仕様

Technical Specification
Source
• Light source type: 16x 40W MSL™ RGBBAL LED multichips
• LED life expectancy: min. 50.000 hours
• Typical lumen maintenance: L70/B50 @ 50.000 hours
• CRI: 96, TLCI: 97, TM-30-18 Rf: 92, TM-30-18 Rg: 99
Optical system
• Robe’s proprietary optical design
• Field angle: Asymmetrical field angle 85° x 45°
• Opti-6™ - A 6:1 height-to-distance ratio asymmetrical optical system, producing a flat uniform field coverage even
within close proximity to the cyclorama
• Highly efficient component optics
• Fixture total lumen output:
• RLCT™ Innovative lens coating technology (Patent pending)
Dynamic Effects and Features
• Colour mixing: CMY/RGB or RGBAL
• 4 individually controllable LED zones
• Variable CCT: 2.700K - 8.000K
• Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K
(red shift and thermal delay)
• DataSwatch™ filters: pre-programmed 237 colours and tones including most used whites 2.700K, 3.200K, 4.200K,
5.600K and 8.000K
• Pre-programmed pixel effects with colour, dimming and strobe chases, waves and pulses at variable speed and
direction
• Pre-programmed random strobe & pulse effects
• Electronic strobe effect with variable speed up to 20 Hz
• High resolution electronic dimming: 0 - 100%
• L3™ - (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
• Extremely quiet operation suitable for all types of production in Theatre and TV
• Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
• MAPS™ - Motionless absolute positioning system for internal movement affecting beam distribution (Patented)
• AirLOC™ (Less Optical Cleaning) technology greatly reduces the level of airborne particles drawn over the optical
elements. This increases the overall performance, light quality and time between routine cleaning and maintenance.
• VertiSpot™ - Unique, motorised vertical crossover point control for superior blending and vertical output variance
(patented)
Control and programming
• Setting & Addressing: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning,
operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 88 steps), built-in
analyser for easy fault finding
• Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN, Kling-Net
• REAP™ - Robe Ethernet Access Portal
• Wireless CRMX™ technology from Lumen Radio - on request
• Epass™: Ethernet pass through switch which sustains Ethernet integrity, when the fixture has no power, to
automatically maintain network connectivity
• DMX Protocol modes: 2
• Control channels: 38, 42
• RGBW / CMY: 8 or 16 bit
• Dimmer: 8 or 16 bit (internal 18 bit)
Thermal specification
• Maximum ambient temperature: 40°C (104°F)
• Maximum surface temperature: 70°C (158°F)
• Minimum operating temperature: -5°C (23°F)
• Total heat dissipation: max. 1890 BTU/h (calculated)
Electrical specification and connections
• Power supply: Electronic auto-ranging
• Input voltage range: 100-240 V, 50/60 Hz
• Power consumption: 740 W at 230 V / 50 Hz
• Power connector in/out: Neutrik powerCON TRUE1 in/out
• DMX and RDM data in/out: Locking 5-pin XLR
• Ethernet port in/out: RJ45 for Embedded Epass™ switch 10/100 Mbps
• Embedded Ethernet switch 10/100 Mbps
Approvals
• CE Compliant
• cETLus Compliant
Mechanical specification
• Height: 244 mm (9.5")
• Width: 1019 mm (40.1")
• Depth: 336 mm (13.2")
• Weight: 34.5 kg (76.0 lbs)
• Ingress protection rating: IP20
Rigging
• Mounting points: 2 pairs of 1/4-turn locking points
• 2x Omega adaptors with 1/4-turn quick locks
• Universal operating position
• Safety cable attachment point
Included items
• User Manual
• Power cord including powerCON TRUE1 In connector
• Mounting adaptor: 99018677
Optional accessories
• Safety wire 36 kg: 99011963
• Omega Clamps CL-regular 2 pcs: 10980033
• Doughty Trigger Clamp: 17030386
• Daisy Chain powerCON TRUE1 In/Out, EU, 2m, Indoor: 13052439
• Daisy Chain powerCON TRUE1 In/Out, US, 2m, Indoor: 13052440
• Daisy Chain powerCON TRUE1 In/Out, EU, 5m, Indoor: 13052444
• Single Top Loader Case: 10120359-01
• Dual Top Loader Case: 10120348-01
Legal
• T32 Cyc™ is a Trademark of Robe lighting s. r. o.
• T32 Cyc™ is patented by Robe lighting s. r. o. and protected by one or more pending or issued patents
