Robe FOOTSIE2 Slim WW（フットシー2 スリム WW）
商品詳細
Time to uplift your footlights and make those feet shine! With its sleek, low design, our IP65-rated FOOTSIE Slim, with reduced footprint takes footlights into the modern age.
48 x RGBW/TW/WW LED single chip
Light output
4.940 lm
Zoom range
Asymmetrical field angle 55° x 50°
Light source type: 48 x 4W WW/TW or 3W RGBW High Power Single Chip LEDs
LED life expectancy: min. 50.000 hours
Typical lumen maintenance: L70/B50 @ 50.000 hours
CRI:
WW 90+
TW 85+
RGBW 70+
Optical system
Robe’s proprietary optical design
Field angle: Asymmetrical field angle 55° x 50°
Fixture total lumen output:
WW: 7.115 lm
TW: 7.240 lm
RGBW: 4.940 lm
Optional diffusers:
Medium frost filter 20° x 1°
Wide frost filter 60° x 30°
SPREAD™ (Shield Protection, Reflection Elimination, Diffusion) The Shield is covering direct viewing of the led sources from the side of audience (Patent pending)
Dynamic Effects and Features
Colour mixing mode RGBW/CMY or TW
4 individually controllable LED zones
+ - Green correction function
CCT:
WW 3000K
TW Variable 2.700K - 6.500K
RGBW Variable 2.700K - 8.000K
Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4200K (red shift and thermal delay)
DataSwatch™ filters: pre-programmed 237 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K
Pre-programmed random strobe & pulse effects
Electronic strobe effect with variable speed up to 20 Hz
High resolution electronic dimming: 0 - 100%
L3™ - (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black
Extremely quiet operation suitable for all types of production in Theatre and TV
Cpulse™ special flicker-free management for HD and UHD cameras, ready for 8K and 16K
BluMark™ safety low-level blue LED indication of stage edges without affecting lighting states
PIP™ - Performer Indication Point – separately controlled RGB LEDs at 10 cm spacing provide performers with alignment points (Patent pending)
Control and programming
Setting & Addressing: two-row LCD display & 4 control buttons, stand-alone operation with 3 editable programs (each up to 40 steps)
NFC app controller
Wireless CRMX™ technology from Lumen Radio
Protocols: USITT DMX-512, RDM
DMX Protocol modes: 3
Control channels:
WW: 1, 13, 26 channels
TW: 2, 20, 33 channels
RGBW: 5, 36, 49 channels
RGBW / CMY: 8 or 16 bit
Variable CCT: 8 bit
+ - Green correction: 8 bit
Dimmer: 8 or 16 bit (internal 18 bit)
Noise Levels
Cooling system: Convenction
Thermal specification
Maximum ambient temperature: 45°C (113°F)
Maximum surface temperature: 50°C (122°F)
Minimum operating temperature: -20°C (-4°F)
Total heat dissipation: max. 218 BTU/h (calculated)
Electrical specification and connections
Power supply: Electronic auto-ranging
Input voltage range: 120-240 V, 50/60 Hz
Power consumption: max. 85W
Power connector in/out: IP65 Neutrik powerCON TRUE1 in/out
DMX and RDM data in/out: IP65 Locking 5-pin XLR connectors
Mechanical specification
Height: 52 mm (2.04")
Width: 1229 mm (48.38")
Depth: 228.1 mm (8.98")
Weight:
13.3 kg (29.32 lbs)
15.9 kg (35.05 lbs) with diffuser
Ingress protection rating: IP65
IK Rating: IK06
Included items
User Manual
Daisy Chain powerCON TRUE1 In/Out, EU or US, 0,90m, Outdoor
Optional accessories
Diffusion filter medium: 10980821
Diffusion filter wide: 10980823
Angled corner 15°: 10980983
Angled corner high 15°: 10980987
Angled corner 30°: 10980984
Angled corner high 30°: 10980988
Angled corner 60°: 10980985
Angled corner high 60°: 10980989
Angled corner 90°: 10980986
Angled corner high 90°: 10980990
End cap:
R: 10980991
L: 10980992
Eight/Quad Top Loader Case ROBIN Footsie1 / Footsie2 slim: 10120351
Power cord including powerCON TRUE1 In connector EU: 13052276-01
Power cord including powerCON TRUE1 In connector US: 13052277-01
Legal
FOOTSIE2™ Slim is Registered Trademark of Robe lighting s. r. o.
FOOTSIE2™ Slim is patented by Robe lighting s. r. o. and is protected by one or more pending or issued patents
