Portman S-TRIBE（S-トライブ）

Completely new, unique design. Perfect for building bigger structures, where your creativity is the only limit.

A combination of very strong tungsten emulated main LED sources and RGBW strips are perfect for any stage and any mood of an event.

特徴

MAGICAL POWERS
5 x strong warm white LED
• tungsten emulation
• smooth dimming
• warm on lower values
• bright and blinding on higher values

10 x LED RGBW strips
• saturated colours
• smooth dimming and colour mixing
• separate control

Auto Orientation™
automatic change of channels order
TOP <> BOTTOM LEFT <> RIGHT

Quick Joint System™
Easy system of joining fixtures together and brackets with no screws

Hi-class electronics
• 6 DMX modes
• Colour Feedback System™
• RDM
• W-DMX option
• macros
• power through

仕様

Dimensions 118 x 15 x 18 cm (46.5 x 5.9 x 7 in)
Weight 8 kg (17.5 lbs)
Rigging - 2 x 12 mm (1/2 in) holes for clamp on back
- base (included)
- adaptor (included) with 12 mm (1/2 in) hole for clamp and/or base [Quick Joint System™]
Mounting position Any
Input voltage 100-240V 50Hz/60Hz
Power consumption max 280W
Power connector PowerCon TRUE1 power through
Control connector - 5 PIN XLR (both: in & out)
- Art-Net (in)
Light sources - 5 x LED dim-to-warm white
- 10 x RGBW strips
Color temperature - 1600-3200K
- RGBW
CRI >90
Optics - High reflective hammered reflector
- Opal diffuser
Control features - 6 DMX modes (12-97 DMX channels)
- Art-Net
- RDM
- macros
- W-DMX (optional module)
User interface - High-contrast LCD display
- Highlighted buttons
Warranty 24 months
IP rating IP20
What's in the box - Fixture
- 2m power cord (PowerCon TRUE 1<-> no plug)
- Base
- Adaptor for a hook or a base [QJS™]
- User manual
Libraries: go to PORTMAN® SUPPORT PORTAL
