ENTTEC 12V RGBW 60-LEDs/m long-range pixel strip black PCB（12V RGBW 60-LEDs/m ロングレンジピクセルストリップ black PCB） [8PXB60-RGBW-12V-B]

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

12V RGBW long-range LED pixel strip for professional applications.

ENTTEC’s 8PXB60-RGBW-12V series are 12V, 60-LED-per-meter, addressable RGBW LED pixel strips designed for long-range professional architectural and entertainment installations, achieving soft pastels or saturated colors on a large scale.

特徴

60 RGBW LEDs per meter
ENTTEC LED pixel strip boasts 60 color-calibrated RGBW LEDs per meter. Each LED is engineered to offer consistent brightness and extended color gamut.

Bright + super-efficient
With a maximum power consumption of only 17.64 watts per meter, and a lumen capacity of 655.6 lumens per meter, this 12V pixel strip provides a bright and efficient package.

Australian designed for top performance
Designed by ENTTEC for reliable operation in the Australian environment, our professional quality pixel strips use superior thickened copper tracks to reduce the effects of voltage drop and to allow a more even intensity along the length of the strip.

Go further than before
On our 12V 8PXB60-RGBW-12V strip, every consecutive group of three SMD chips behave as one pixel. This means that you can free up extra channels to triple your output capabilities: perfect for controlling longer setups.

Millions of colours
Each pixel can achieve a 32-bit, True Color display. That’s a whopping 4,294,967,296 possible colors for each LED chip!

Extend as you please
Join two lengths together or cut them into a smaller length. You can also operate the tape from up to 300m away using the ENTTEC PLink system. This tape is recommended for indoor use only.

仕様

Connectors 2 x 3-pin JST SM connectors (3A Max)
Input voltage 12V
Max. watts per meter 17.64
Efficacy (lumens per watt) 37.17
DMX channels per pixel 4
Beam angle 120°
Control protocol SM16704 (compatible with UCS2904)
Backup data line No
Pixel mapping order RGBW
PCB color Black or white options
PCB width 10mm / 0.40”
Min. bend radius 30mm / 1.2”
Spacing between cuttable sections 50mm / 1.98”
IP rating IP20
Environmental operating temperature 0°C to 50°C / 32°F to 122°F
Environmental operating humidity 5- 95% (non-condensing)
Weight (5m roll) 0.18Kg / 0.40lbs
Dimensions (5m roll) 240 x 215 x 16mm / 9.45 x 8.47 x 0.63”
Shipping weight (5-roll carton) 0.80Kg / 1.76lbs
Shipping dimensions (5-roll carton) 260 x 225 x 93mm / 10.24 x 10.04 x 3.66”
Warranty 1-year return to base manufacturer warranty
Compliance UL / RCM (Aus/NZ), CE / WEEE (EU), UKCA (UK), FCC (USA)
