Chroma Q Color Force II 48 Plus（カラーフォース II 48 プラス）

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

概要

Cyc, Wash & Effects LED Lighting, Simply Amazing!
Cyc, Wash & Effects LED Lighting, Simply Amazing!

Once again, Chroma-Q impresses with Color Force II Plus™, the updated version of the renowned Color Force II™ professional luminaire.

The Color Force II Plus™ boasts enhanced brightness and a richer palette while maintaining the same form factor and character as the market-leading original. The innovative optical system with individually controlled pixels provides smooth, beautiful, and even coverage for any cyc or surface with no unsightly colour shadowing.

Designed for a variety of applications where powerful and precise lighting is essential, including cyc, flood, and wall washing up to 12m.

Available in 0.3m / 1 ft, 1.2m / 4 ft, and 1.8m / 6 ft versions.

特徴

Key Features

Featuring Chroma-Q’s proven award-winning technology
Fully useable along side original Color Force II
Over 4500 / 18,000 / 27,000 hot lumens, respectively
Extremely smooth, uniform output
Unmatched cyc evenness
Homogenised RGBA colour mixing
Rich saturated colours and smooth pastel colours
Pixel control to 76mm / 3 in increments
High CRI of 92
Theatrical grade dimming
Rugged extruded aluminium body
Built-in power supply
Chroma-Q ColorSure™ calibration means superior fixture-to-fixture consistency
Works great in theatre, TV, concert touring, exhibitions, or corporate events
Optional internal LumenRadio
Touchscreen user interface

仕様

Color Force II Plus 48
Product Code CQ1641-2000 Color Force II Plus 48 w/trunnion, TRUE1 to 15-5P Cable, BK
CQ1641-2100 Color Force II Plus 48 w/trunnion, TRUE1 to 15-5P Cable, WH
CQ1641-2500 Color Force II Plus 48 w/trunnion, TRUE1 to 15-5P Cable, RF, BK, with LumenRadio
CQ1641-2600 Color Force II Plus 48 w/trunnion, TRUE1 to 15-5P Cable, RF, WH, with LumenRadio
Net Dimensions 1,181mm x 165mm x 191mm / 46.5" x 6.5" x 7.5"
Net Weight 18 Kg / 40 lb
Shipping Dimensions 1,295mm x 305 mm x 320mm / 51'' x 12'' x 12.5''
Shipping Weight 21 Kg / 46 lb
Power Supply Built-in
Power Input Rating 100-240V AC, 50-60 Hz, 550VA
Power Factor 0.97 @ 120V AC,
0.92 @ 240V AC
Power Consumption 533W @ 120V AC,
533W @ 240V AC
Idle Power Consumption 27W @ 120V AC,
30W @ 240V AC
Typical Power & Current Measurements were done with all LEDs at maximum intensity. Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
Power Connectors In/Out Neutrik powerCON TRUE1
Data Connectors In/Out Neutrik XLR 5-pin
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling System Forced
Operating Temperature 0°C to 40°C
Construction Anodised aluminium extrusion
Colour Black
Built-In Hardware Quick release lever for tilt adjustment
IP Rating IP20
Approvals CISPR 22: 2006/EN55022: 2006 & CISPR 24: 1997/EN55024: 1998, ICES-003: 2004 & FCC Part 15 Subpart B: 2007, CSA
C22. No. 166-M1983:R2008 UL 573:2003; UL 8750
