ACME ELLIPSOIDAL 40 DMX WW（エリプソイダル 40 DMX WW）

概要

ELLIPSOIDAL 40 DMX series, is DMX version. Uniform light, sharp image edge, and self-locking focus lens.The product takes advantage of the heat pipe heat conduction and housing feature to dissipate heat without fan to prolong LED life.

特徴

Light source: 1×36W warm white LED
Color Temperature: 3200±150K
Beam Angle: 19°/26°/36°/50°
Flicker free management

仕様

Model

E-40D WW

Light Source

Light source: 1×36W warm white LED
LED life expectancy: 20000 hours* manufacturer specification
Color Temperature: 3200±150K

Optical system and effects

Advanced optical system to ensure image quality, clear and sharp
CRI：≥95
CQS：≥95
TLCI：≥95

Control and Program

4-buttons
Display: LCD display
Protocols: DMX512,RDM
DMX Protocol modes: 2
Control channels: 1,2
Upgrade the firmware via DMX link

Electrical and Connectors

Power supply with electronic auto-ranging
Input voltage range: AC 100~240V,50/60Hz
Power consumption: 32 W
Power in/out: Power wire
Data in/out: 3-pin or 5-pin XLR

Fixture Specification

Height: 100 mm (3.9")
Width: 158 mm (6.2")
Depth: 273 mm (10.7")
Weight: 2 kg (4.4 lbs)

Work Environment

Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C

Approvals

CE Compliant

Installation

Horizontally or vertically mounting are available
Operating position is universal
The feet support with 1 locking points
Safety Rope Hole

Included Items

Digital User Manual*1
Gel frame*1
Gobo Slot*1
Metal gobo*1
Safety cable*1

Optional Accessories (with item code)

Clamp：2060000300（C-01）
Signal Line：3-pin or 5-pin signal line
