ACME THEATRE SPOT 150 WW（シアタースポット 150 WW）

概要

The ACME THEATRE SPOT 150 WW is a powerful single source LED luminaire, equipped with 150W Warm White 3150K±150K led engine, which can produce CRI≥94 clear light. It delivers 14° to 55° wide range beam angle with an efficient optical system at 1:4 ratio. The advanced cooling fan is carefully selected from top brands only to offer you a better cooling and silent operation. Fitted with special patented clamp structure, the Theatre Spot can easily handle different installation and avoid any unexpected movement making the light out of focus. What's more, the Theatre Spot provides you a smooth fading performance with 4 variable dimming curves and 2 optional dimming speeds. Equipped with flicker free operation, rotating barn door and rotating bracket, this light-weight fixture is suitable for many applications, such as big shows, exhibitions, evening performances, dramas, film shooting, etc.

特徴

Light source: 1×150W warm white LED
Color Temperature: 3150±150K
Motorized focus
Zoom range: 14°~55°
Manual linear dimming
4 dimming curves,2 optional dimming speed
0~100% smooth dimming
Low noise under 25dB@1m
Rotating cover, rotating bracket with limiting function
Flicker free management

仕様

Model

TS-150 WW

Light Source

Light source: 1×150W warm white LED
LED life expectancy: 20000 hours* manufacturer specification
Color Temperature: 3150±150K

Optical System and Effects

Advanced optical system to ensure image quality, clear and sharp
High - efficiency zoom optical system, ratio 1:4
Zoom range: 14°~55°
CRI：≥94
CQS：≥94
TLCI：≥96

Control and Program

4-buttons
Display: LCD display
Protocols: DMX, Master/Slave, Manual, Art-Net
DMX Protocol modes: 2
Control channels: 2,3
Upgrade the firmware via DMX link

Electrical and Connectors

Power supply with electronic auto-ranging
Input voltage range: AC 100–240 V, 50/60 Hz
Power consumption: 190 W
Power in/out: Power Connector input/output
Data in/out: 5-pin XLR
Art-Net input: RJ45

Fixture Specification

Height: 264 mm (10.3")
Width: 278 mm (10.9")
Depth: 406 mm (15.9")
Weight: 8.6 kg (18.9 lbs)

Work Environment

Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C

Installation

Horizontally or vertically mounting are available
Operating position is universal
The feet support with 3 locking points
Safety Rope Hole

Included Items

Power Cable
Digital User Manual
Barn door

Optional Accessories (with item code)

Flight Case：
3205001220（2 in 1）
3205001164（8 in 1）
Clamp：2060001625（C-150B）
Signal Line：5-pin signal line
Safety cable: 2060000200（SW-02）
Rotating barn door：63580845
Cellular grid：63580925
