HIGHLITE Showtec Spectral Revo UV [43641]
商品詳細
The Power Of Entertainment - Showtec Spectral Revo 6, UV, Daylight and Tungsten. Order Codes 43640, 43641, 43642 and 43643 from Highlite International on Vimeo.
100 W UV LED Par
Fixed 45° beam angle
IP65 (dust and water resistant, fit for outdoor use)
PC Lens optics for a homogeneous output
Silent operation
The Showtec Spectral Revo UV is a 100 watt UV LED Spot for a strong homogenous UV output, suitable for in- and outdoor applications. Each function, including its 0–100 % dimmer and 0–25 Hz strobe, is controllable via DMX and Master/Slave in either Manual and Auto run mode. The Spectral Revo UV projects a soft field of light with a 45° fixed beam angle. Its compact and lightweight 6.5 kg design, with IP65 rating, -10~40 °C operating temperature range and Forced Convection cooling, fits at almost any environment.
■仕様
Source
Light Source Type
LED
Light Source Quantity
1
Light Source Power
125 W
LED Colour Type
UV
Luminous Flux (Total)
3051 lm
Optical
Beam Angle (Circular)
45°
Control and Programming
Control Mode
Auto, Built-in Program, DMX, Manual
DMX Channels
1, 2, 4
Protocols
DMX, RDM
Display
OLED
Dynamic Effects
Dimmer
0-100 %
Strobe
0-20 Hz
Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
110 W
Power Connector In
powerCON TRUE1
Power Connector Out
powerCON TRUE1
DMX Connector
Dedicated 5P IP65 In/Out
DMX Connector In
Dedicated 5P IP65
DMX Connector Out
Dedicated 5P IP65
■サイズ
Mechanical Specifications
Length (mm)
425 mm
Width (mm)
320 mm
Height (mm)
219 mm
Weight
6.5 kg
IP Rating
IP65
Housing
Aluminium die-cast
Colour
Black
Product Properties
Cooling
Forced Convection
Rigging
Mounting Options
Clamp, Quick-Lock, Surface
Safety Attachment
Yes
Thermal Specifications
Maximum Ambient Temperature
40 °C
Minimum Operating Temperature
-10 °C
Included Items
Included Cables
powerCON TRUE1 cable
Included Accessories
User Manual
Included Rigging
Bracket, Safety Cable
■メーカーサイト
https://www.highlite.com/en/products/entertainment-lighting/spots/spots-outdoor/43641-spectral-revo-uv.html
