HIGHLITE Showtec Media Panel 100（ショーテックメディアパネル 100） [33301]

販売価格はお問い合わせください。

返品特約に関する重要事項

商品詳細

Showtec Media Panel 50 and 100. Product codes 33300 and 33301 from Highlite International on Vimeo.

100 W Daylight White Media Panel
Suitable for short-distance media lighting
Wide 87° field angle
High >98 CRI for accurate 5000 K colour rendering
Bright 7800 lumen output

仕様

Source
Light Source Type
LED
Light Source Quantity
392
Light Source Power
0.25 W
LED Colour Type
White
Illuminance @ 2 m
2231 lx
Illuminance @ 3 m
892 lx
Luminous Flux (Total)
7829 lm
CRI
98
CCT
5000 K

Optical
Beam Angle (Circular)
87°
Field Angle (Circular)
143°
Control and Programming
Control Mode
Manual

Dynamic Effects
Dimmer
0-100 %

Electrical Specifications and Connections
Power Supply
24 V DC
Power Consumption
100 W
Power Connector In
Low Voltage DC plug

サイズ

Mechanical Specifications
Length (mm)
480 mm
Width (mm)
70 mm
Height (mm)
340 mm
Weight
2.6 kg
IP Rating
IP20 (indoor use only)
Housing
Aluminium
Colour
Dark Gray

Product Properties
Cooling
Convection
Type Floodlight
Symmetric

Rigging
Mounting Options
Bracket

Thermal Specifications
Maximum Ambient Temperature
45 °C

Included Items
Included Cables
IEC cable
Included Accessories
Adapter, Barndoor, Spigot Adapter 16 mm (5/8)
