HIGHLITE Showtec Dominator(ショーテック ドミネーター) [43153]
商品詳細
Showtec Dominator ordercode 43153 from Highlite International on Vimeo.
LED, Laser & Strobe Effect
200 mW RG Laser
RGBWA Colours
8 Power strobe LEDs
仕様
SourceLight Source Type
LED
Light Source Quantity
5
Light Source Power
3 W
LED Colour Type
RGBWA, White
LED Strobe
Yes
LED Strobe Quantity
8
LED Strobe Power
1 W
Drive Current
0.35 A
Laser Power
200 mW
Laser Source
DPSS
Laser Class
3B
Laser Colour
Red, Green
Laser Power (Total)
200 mW
Laser Power (Red)
150 mW
Laser Wavelength (Red)
650 nm
Laser Power (Green)
50 mW
Laser Wavelength (Green)
532 nm
Control and Programming
Control Mode
Auto, DMX, Master Slave, Sound
DMX Channels
9
Display
7-segment, LED
Electrical Specifications and Connections
Power Supply
100-240 V AC 50-60 Hz
Power Consumption
66 W
Power Connector In
IEC
Power Connector Out
IEC
DMX Connector
XLR 3P In/Out
DMX Connector In
XLR 3P
DMX Connector Out
XLR 3P
サイズ
Mechanical SpecificationsHeight (mm)
312 mm
Width (mm)
307 mm
Depth (mm)
170 mm
Weight
3.95 kg
IP Rating
IP20 (indoor use only)
Housing
Metal
Colour
Black
Product Properties
Cooling
Axial fan
Safety Features
Interlock, Key Switch
Rigging
Mounting Options
Clamp
Thermal Specifications
Maximum Ambient Temperature
35 °C
Product Compliance
Laser Classification Standard
EN-IEC 60825-1:2007
Included Items
Included Cables
IEC cable
Included Rigging
Bracket
