High End Systems SolaFrame 1000 UB（ソラフレーム 1000） [2570A1200-B]

SolaFrame 1000 fixture is the go-to workhorse automated framing fixture for lighting designers. With 20,000 lumen
output, full framing shutters, rotating and fixed gobo wheels, a redesigned CMY and CTO color mixing system, replaceable color wheels, and animation effects. It has a feature set as varied as your lighting designs. The SolaFrame 1000 is a star performer in all professional production environments.

特徴

・White LED Engine
・480 W Ultra-Bright engine producing 20,000 field lumens or a High CRI Engine featuring incredibly accurate color rendering
・Full framing shutter system
・CMY/CTO-Linear color mixing system
・Six plus open position replaceable color wheel
・Iris and Light Frost
・Rotating Prism
・Sharp edge focus throughout 12°–40° zoom range
・Eight position plus open Fixed Gobo Wheel with interchangeable gobos
・Seven position plus open Rotating Gobo Wheel with interchangeable gobos
・Continuously rotating variable Animation Wheel
・TM-30 Filter boosts Ultra-Bright engine to 85+ CRI
・Patented Lens Defogger

■Source
・Engine Ultra-Bright White Engine
・LED Details 480 W
・Max Field Lumens 20,000 lumens
・LPW 42 lumens per watt
・LED Life 50,000 hours
・Native CCT 6700 K
・Transferable Light Engine Yes

■Color
・Color Mixing Cyan, magenta, yellow, CTO-Linear
・Color Temperature Variable down to 2800 K
・Color Wheel Six (6) interchangeable dichroic chips plus open includes TM-30 Filter standard

■Optical
・Beam Angle Range 12°–40°
・Gate Size 25 mm
・Aperture Size 108 mm
・Pattern Projection Rotating and indexable wheel with seven (7) patterns plus open Fixed wheel with eight (8) patterns plus open
・Animation Rotating animation wheel LED branch animation Additional accessories available
・Frost Light frost
・Additional accessories availalble
・Iris 16-blade iris
・Framing Four-plane, full-curtain framing system with 90° module rotation
・Flicker Control/Hz Range 100 Hz, 2.4 kHz, or 16 kHz

■Control
・Input Method DMX (5-pin) or Ethernet
・Protocols DMX via RS-485
・Art-Net or sACN via Ethernet
・Ethernet Pass-Thru Passive Ethernet in and thru with and without power
・Data Conversion Patented data conversion system for: DMX to Ethernet Ethernet to DMX
・Modes (Footprint) One (48)
・RDM Functions Yes
・UI Type Full color graphical UI with 6 button navigational control
・Local Control Yes
・Dimming Performance 16-bit, DMX controlled

■Electrical
・Voltage Range 100–240 VAC, 50–60 Hz
・Input Method powerCON TRUE1
・Wattage (Standard/+Defogger) 917 W / 958 W
・Current (Max) 9.6 A @ 100V
・Inrush (first half-cycle) 120 V: 53.6 A　230 V: 108 A

■Thermal
・Ambient Operating Temp -10°–45° C
・Fan Mode Three modes: Standard, Studio, and Continuous
・Stationary Noise Standard - 42.8 dBA Background noise measured at 39.5 dBA
・Lens Defogging Patented Lens Defogger included

■Physical
・Pan and Tilt Range 540° pan, 265° tilt
・Max Pan/Tilt Speed 2.1 sec for 360°, 1.2 sec for 180°
・Materials Steel and aluminum frame with molded plastic covers
・Color Options Black, white by request
・Mounting Options Any orientation
・IP Rating IP20

■Included Accessories
powerCON TRUE1 to bare end
fixture tail
Two (2) clamp brackets
Safety cable

サイズ

・Weight 31.3 kg

参照

■メーカーサイト
https://www.etcconnect.com/Products/Automated-Lighting/SolaFrame/1000/Features.aspx
