GANTOM Gantom DMX Flood(ガンタム) [新品]
商品詳細
The Gantom DMX Flood is a 4W color controllable LED floodlight for professional applications. Featuring a non-linear dimming curve, the Gantom DMX Flood can be dimmed with high precision even at the lowest intensity levels. Homogeneous optics smoothly blend the colors of the internal quad chip LED to produce a clean projected field. Objects blocking this light source will cast razor sharp shadows without color separation. High frequency hybrid modulation allows the Gantom DMX
Flood to be used in video applications with minimal on-camera flickering. This fixture can even be battery powered for portable operation, perfect for fill lighting in hard to reach locations. The Gantom DMX Flood is configured using our DMX Programmer app, available free for Apple and Android devices.
■特徴
・Homogeneous wide beam optics
・Available in dynamic white and RGBW configurations
・Also available in narrow beam angle configuration (see Gantom DMX Spot)
・Non-linear dimming curve for smooth fading without visible “steps” in output intensity
・14 bit dimming compressed into single 8 bit channel gives precision control without using extra channels
・Minimized on-camera flicker
・DMX address and colors configured via DMX Programmer app
・Less than 5W at full output
・Integrated DMX receiver
・Integrated quad channel constant current driver for consistent output
・Storm Series version for permanent outdoor installations also available
■アプリケーション
・Themed entertainment (dark rides, Halloween attractions, bars, nightclubs, casinos)
・Theater and stage accent lighting
・Mobile displays
・Floral centerpieces
・Retail spaces
・Architectural accent lighting
・General purpose accent lighting
・Props and animatronics
・Special effects lighting
・Temporary event lighting
■■PRODUCT DETAILS
■GANTOM DMX FLOOD - DYNAMIC WHITE
・SKU GT21
・Color Temperature 3000K-6500K
・DMX Channels 2
・Cable Options
Power Connector:
2.1mm DC jack with screw terminal adapter for Power
Signal Connector:
3.5mm (1/8") TRS jack with screw terminal adapter
■GANTOM DMX FLOOD - DYNAMIC WHITE - PRO CABLE CONNECTOR
・SKU GP221
・Color Temperature 3000K-6500K
・DMX Channels 2
・Cable Options Power and Data integrated into a single sealed locking connector
■GANTOM DMX FLOOD ? RGBW
・SKU GT22
・Color Temperature 6500K (white channel only)
・DMX Channels 4
・Cable Options
Power Connector:
2.1mm DC jack with screw terminal adapter for Power
Signal Connector:
3.5mm (1/8") TRS jack with screw terminal adapter
■GANTOM DMX FLOOD ? RGBW - PRO CABLE CONNECTOR
・SKU GP222
・Color Temperature 6500K (white channel only)
・DMX Channels 4
・Cable Options Power and Data integrated into a single sealed locking connector
■仕様
・Max wattage 4.8W
・Input Voltage 9-15VDC (12VDC nominal)
・Current Draw < 400mA @ 12VDC
・Power Supply for use with class 2 regulated switching power supply
・Beam Angle 28 degrees
・Field Angle 66 degrees
・Ingress Protection IP65
・LED Cree XLamp MC-E
・Certifications UL and CE
・Connector Options Standard Connectors 2.1mm DC jack with screw terminal adapter for Power
・3.5mm (1/8") TRS jack with screw terminal adapter
・Gantom Pro Cable Connector waterproof locking connector which combines both power and DMX signal in a single cable
■DYNAMIC WHITE OUTPUT: COOL WHITE
・Distance Center Beam Beam Width
1.0m (3.3ft) 407lx (37.8fc) 0.5m (1.6ft)
2.0m (6.6ft) 113lx (10.5fc) 1.0m (3.3ft)
3.0m (9.8ft) 50lx (4.7fc) 1.5m (4.9ft)
■DYNAMIC WHITE OUTPUT: WARM WHITE
・Distance Center Beam Beam Width
1.0m (3.3ft) 286lx (26.6fc) 0.5m (1.6ft)
2.0m (6.6ft) 79lx (7.3fc) 1.0m (3.3ft)
3.0m (9.8ft) 35lx (3.3fc) 1.5m (4.9ft)
■RGBW OUTPUT: ALL LEDS ON
・Distance Center Beam Beam Width
1.0m (3.3ft) 243lx (22.6fc) 0.5m (1.6ft)
2.0m (6.6ft) 71lx (6.6fc) 1.0m (3.3ft)
3.0m (9.8ft) 28lx (2.6fc) 1.5m (4.9ft)
■RGBW DMX CHANNEL DESCRIPTIONS
・Channel Description
・Ch 1 ? Red Controls red channel
・Ch 2 ? Green Controls green channel
・Ch 3 ? Blue Controls blue channel
・Ch 4 ? White Controls white channel
■DYNAMIC WHITE DMX CHANNEL DESCRIPTIONS
・Channel Description
・Ch 1 ? Cool White Controls cool white channel
・Ch 2 ? Warm White Controls warm white channel
■データシート
http://www.gantom.com/wp-content/uploads/2018/05/Gantom_DMX_2018.pdf
■ユーザーガイド
http://www.gantom.com/wp-content/uploads/2018/07/Gantom-DMX-User-Guide-1.3.pdf
■メーカーサイト
https://www.gantom.com/lighting-fixtures/gantom-dmx-flood/
